Label Cutting Machine

Picture Gallery

Watch Video

E-Catalogue

Main Features:

  • Fully Touch-screen controlled (7.00")

  • Robust and maintenance free design

  • Four synchronized servos

  • Tension Control

  • Edge guider/ web liner

  • Air shaft

  • Programmable conveyor

  • Double stroke cutter programme for corner cut pouches

Machine is divided in following section:

  • Conveyor ​
  • Cutter
  • Registration
  • Print/Mark section
  • Dancer
  • Inline Perphoration
  • (Rotary perphoration)
  • Unwinder
  • Edge guider

Production Variety:



  • Sheet Cutting
  • Label cutting
  • Perphorated sleeves
  • Sleeves cutting

Specifications:

                                                max.     min.

paper size(mm)                            500     100

label length(mm)                          350       25

roll diameter(mm)                        1000    100

machine speed* (cpm)                  200       30



  • Imported motors and gear boxes

  • Imported Photo sensor for print mark registration

M/c Code: HILCMM-500
